Thabiso Steel is a reputable manufacturer and supplier of top-notch steel products located in Cape Town, South Africa. They specialize in Carbon Steel EN 10216-4 pipes and are dedicated to providing precision-engineered piping solutions that adhere to global standards. With a solid reputation for reliability, technical know-how, and prompt delivery, Thabiso Steel caters to a diverse array of industries, including construction, energy, petrochemical, and mechanical engineering. Their advanced manufacturing capabilities and strict quality assurance processes guarantee that each product performs reliably, even in tough conditions. Thabiso Steel is a trusted partner for durable and cost-effective steel piping solutions throughout South Africa and beyond.
Carbon Steel EN 10216-4 pipes are seamless, non-alloy pipes designed to handle pressure at elevated temperatures. Typically, their composition includes carbon (≤0.25%), manganese (≤1.20%), phosphorus (≤0.025%), and sulfur (≤0.015%). These pipes are celebrated for their exceptional strength, durability, and ability to withstand high-pressure and high-temperature environments. They boast a minimum yield strength of 235 MPa and a tensile strength ranging from 360 to 510 MPa, depending on the pipe dimensions and heat treatment. Available in either normalized or thermomechanically processed conditions, they are perfect for pressure vessels and structural applications.
| Steel Grade | Steel No. | C max. | Si max. | Mn | P max. | S max. | Cr max. | Mo max. | Ni max. | Al max. | Cu max. | N max. | Nb max. | Ti max. | V max. | Nb+Ti+V max. |
| P275NL1 | 1.0488 | 0,16 | 0,40 | 0,50 to 1,50 | 0,025 | 0,02 | 0,30 | 0,08 | 0,50 | 0,02 | 0,30 | 0,02 | 0,05 | 0,04 | 0,05 | 0,05 |
| P275NL2 | 1.1104 | 0,16 | 0,40 | 0,50 to 1,50 | 0,025 | 0,015 | 0,30 | 0,08 | 0,50 | 0,02 | 0,30 | 0,02 | 0,05 | 0,04 | 0,05 | 0,05 |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 490 | 650 | – | 22 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel EN 10216-4 Pipe products in Cape Town, South Africa. Specializing in premium steel materials, we offer a diverse range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a strong commitment to timely delivery and exceptional customer service, Jaxon Steel provides top-grade materials that deliver outstanding performance across various industrial applications. Trust Jaxon Steel for all your Carbon Steel EN 10216-4 Pipe needs.
| 1/8″ IPS(.405″ O.D.) | 3 1/2″ IPS( 4.000″ O.D.) |
|---|---|
| SCH 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/4″ IPS(.540″ O.D.) | 4″ IPS(4.500″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 3/8″ IPS(.675″ O.D.) | 5″ IPS( 5.563″ O.D.) |
| SCH 10, 40, 80 | SCH 10, 40, 80, 160, XXH |
| 1/2″ IPS(.840″ O.D.) | 6″ IPS(6.625″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 3/4″ IPS(1.050″ O.D.) | 8 ” IPS(8.625″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 5, 10, 40, 80, 120, 160, XXH |
| 1″ IPS:(1.315′ O.D.) | 10″ IPS(10.750″ O.D.) |
| SCH 5, 10, 40, 80, 160, XXH | SCH 10, 20, 40, 80 (.500), TRUE 80(.500) |
| 1-1/4″ IPS(1.660″ O.D.) | 12″ IPS(12.750″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500) |
| 1-1/2″ IPS(1.900″ O.D.) | 14″ IPS(14.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10 (.188), SCH40 (.375) |
| 2″ IPS(2.375″ O.D.) | 16″ IPS(16.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH10(.188), SCH40(.375) |
| 2 1/2″ IPS(2.875″ O.D.) | 18″ IPS (18.000″ O.D.) |
| SCH 10, 40, 80, 160, XXH | SCH-40 (.375) |
| 3″ IPS( 3.500″ O.D.) | |
| SCH 5, 10, 40, 80, 160, XXH |
| Execution | Size Range | OD Tolerance | Wall tolerance |
|---|---|---|---|
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm |
| Hot-rolled peeled tube | All sizesWall < 12 mmWall – 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) |
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness< 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm |
Carbon Steel EN 10216-4 pipes are commonly utilized in high-pressure systems where durability and heat resistance are essential. They are particularly well-suited for power plants, industrial boilers, heat exchangers, and pressure vessels due to their mechanical strength and thermal stability. In the oil and gas industry, these pipes are used for transporting steam, gas, and fluids at high temperatures. They also find applications in chemical processing plants and refineries. Their seamless design ensures leak-free performance, making them ideal for operations where safety is paramount.
ThabisoSteel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Cape Town, South Africa.
