Jaxon Steel is a highly respected manufacturer and supplier located in Cape Town, South Africa. This company is specifically involved in providing carbon steel items. The strength, durability, and resistance of the Carbon Steel DIN 2609 Pipe makes it very good. These are widely used pipes in the various industrial sectors where oil, gas, and construction activities take place, thereby withstanding the stringent conditions of such environments. Quality-oriented, we provide precision engineering solutions for diversified needs.
The carbon steel DIN 2609 pipe mainly consists of carbon, manganese, and a very small percentage of other elements including silicon, phosphorus, and sulfur. The mechanical properties it possesses include high strength and toughness. The tensile strength varies between 400-550 MPa with the yield strength in the range of 250-350 MPa and elongation in the range of 20-30%. It also shows excellent toughness properties and resistance to wear and corrosion that give it durability for high pressure services. It is designed to withstand extreme conditions in industries like oil, gas, and construction while maintaining reliable performance and structural integrity.
| Standard | AISI, DIN, EN, GB, IS, JIS, ASTM, ASME Pipe |
|---|---|
| DIN 2609 Grade St35-8 Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| Mild Steel DIN 2609 Grade St35-8 Welded Pipe Size | 5.0 mm – 1219.2 mm |
| DIN Gr. 2609 ST35-8 Steel EFW Pipe size | 5.0 mm – 1219.2 mm |
| Grade ST 35-8 DIN 2609 Pipe Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Carbon Steel DIN 2609 Grade ST 35-8 Pipe Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| DIN 2609 Gr St35-8 Carbon Steel Seamless Pipe Size | 3.35 mm OD To 101.6 mm OD |
| Grade ST 35-8 DIN 2609 Welded Pipe Size | 6.35 mm OD To 152 mm OD |
| CS DIN 2609 Grade St35-8 Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| DIN2609 ST35-8 Steel Pipe wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| DIN 2609 Gr St35-8 Length | Single Random, Double Random, Standard & Cut length Pipe & Tube |
| DIN 2609 Gr. St 35-8 Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Low Temperature Carbon Steel DIN 2609 Grade ST 35-8 Form | Round, Hydraulic, ‘U’ bent or Hollow,LSAW, Boiler, Straight Pipe, Clad Pipe, Rectangular, Square Pipe Etc |
| Mild Steel DIN 2609 Grade St35-8 Type | Welded, Seamless, ERW, EFW, Fabricated Pipe, ‘U’ bent or Hollow, Hydraulic, LSAW, Boiler, Straight Tube, Tube Coil, Round, Rectangular, Square Tube etc |
| ASME B36.19 DIN2609 Grade ST 35-8 End | Plain End, Beveled End, Treaded Pipe & Tube |
| DIN 2609 Grade St35-8 Marking | All DIN 2609 Grade ST 35-8 Carbon Steel Seamless Tubes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| 2609 Gr. ST35-8 Application | Oil Pipe & Tube, Gas Pipe & Tube, Fluid Pipe & Tube, Boiler Pipe & Tube, Heat exchanger Tube |
| DIN Gr. 2609 ST35-8 Steel Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Mechanical Properties | |||||||||
| Yield Strength | Tensile Strength | Elongation A5 min | |||||||
|---|---|---|---|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage | ||||
| 360 | 480 | – | 25 | ||||||
| Outer diameter and wall Thickness | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| Execution | Size Range | OD Tolerance | Wall tolerance | ||||||
| Hot-rolled Pipe | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm | ||||||
| Hot-rolled peeled Pipe | All sizesWall < 12 mmWall – 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) | ||||||
| Cold Worked Pipe cold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness< 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm | ||||||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel DIN 2609 Pipe products in Cape Town, South Africa. Specializing in premium steel materials, we offer a wide range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our diverse selection features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to reliable delivery and exceptional customer service, Jaxon Steel ensures the supply of top-grade materials that deliver excellent performance across various industrial applications. Rely on Jaxon Steel for all your Carbon Steel DIN 2609 Pipe needs.
| DIN | EN | BS | NFA | ASTM | ASME |
| DIN 2609 Grade St 37-0 | – | – | – | – | – |
Carbon Steel DIN 2609 Pipe is widely applied in various industries for its tensile strength and durability. Most often, carbon steel DIN 2609 is used in oil and gas where high pressure involves transporting oil and gas and many fluids. Pipes are also commonly used in the power plant and chemical processing in water treatment. Its excellent resistance to corrosion and wear makes it ideal for construction, manufacturing, and HVAC systems. In addition, the carbon steel DIN 2609 pipe is used in refineries, steam boilers, and pipelines, ensuring reliable performance and structural integrity even in challenging conditions.
