Thabiso Steel stands out as a top-notch manufacturer and supplier located in Cape Town, South Africa. They specialize in crafting high-quality Carbon Steel DIN 2440 Pipes that are designed for strength, durability, and dependable performance across a variety of industrial applications. With a reputation for precision manufacturing and strict adherence to international quality standards, Thabiso Steel delivers pipes that boast excellent mechanical stability, weldability, and resistance to wear and pressure. These Carbon Steel DIN 2440 Pipes are perfect for industries like construction, machinery, automotive, and general engineering, where consistent performance, longevity, and operational efficiency are key.
The composition of Carbon Steel DIN 2440 Pipes primarily includes carbon, along with controlled amounts of manganese, silicon, and trace elements to boost their mechanical properties. This blend results in impressive tensile strength, yield strength, and hardness, while also ensuring great weldability and machinability. Typically, these pipes show a tensile strength ranging from 410 to 560 MPa and a yield strength of about 240 MPa. Their unique combination of ductility, toughness, and dimensional stability makes them well-suited for low- to medium-pressure applications and general industrial use that demands reliable performance and long-lasting durability.
| Steel Grade | C | Si | Mn | Cr | Ni | Mo |
| St 33 | It is not normalized | |||||
| Steel Grade | Tensile Strength,N/mm2(min) | Yield Strength,N/mm2(min) | Elongation, % (min) |
| St 33.2 | 290 – 310 | 185 | 18 |
| DIN 2440 | ||||||
| DN | Zoll | d | s | kg/m | ||
| schwarz | verzinkt | |||||
| 8 | 1/4 | 13.5 | 2.35 | 0.65 | 0.68 | |
| 10 | 3/8 | 17.2 | 2.35 | 0.85 | 0.89 | |
| 15 | 1/2 | 21.3 | 2.65 | 1.22 | 1.27 | |
| 20 | 3/4 | 26.9 | 2.65 | 1.58 | 1.65 | |
| 25 | 1 | 33.7 | 3.25 | 2.44 | 2.55 | |
| 32 | 1 1/4 | 42.4 | 3.25 | 3.14 | 3.28 | |
| 40 | 1 1/2 | 48.3 | 3.25 | 3.61 | 3.77 | |
| 50 | 2 | 60.3 | 3.65 | 5.10 | 5.33 | |
| 65 | 21/2 | 76.1 | 3.65 | 6.51 | 6.80 | |
| 80 | 3 | 88.9 | 4.05 | 8.47 | 8.85 | |
| 100 | 4 | 114.3 | 4.5 | 12.10 | 12.64 | |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel DIN 2440 Pipe products in Cape Town, South Africa. Specializing in premium steel materials, we offer an extensive range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our diverse selection includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a commitment to dependable delivery and exceptional customer service, Jaxon Steel ensures the supply of superior materials that provide outstanding performance across various industrial applications. Trust Jaxon Steel for all your Carbon Steel DIN 2440 Pipe requirements.
| Nominall Width> | Conn- ecting nomin- al width of the flttings according to DIN 2950 and DIN 2980 | Whit- worth- pipe threads according to DIN 2999 Part1 | Tube | Screw thread | Corresponding socket according to DIN 2986 | ||||||||
| Outside diameterd1 | Wall thick- nesss | Weight | Theo- retical screw thread diameter d2 | Threads per 25.4mm | Usable screw thread length J min at a max. | Distance of screw thread dlameter d2 from tube end | Outside diameter | Length | |||||
| Plain-end tube kg/m | socketed tubekg/m | a max. | a min. | min. | min. | ||||||||
| 6 | 1/8 | R 1/8 | 10.2 | 2.0 | 0.407 | 0.410 | 9.728 | 28 | 7.4 | 4.9 | 3.1 | 14 | 17 |
| 8 | 1/4 | R 1/4 | 13.5 | 2.35 | 0.650 | 0.654 | 13.157 | 19 | 11.0 | 7.3 | 4.7 | 15.4 | 25 |
| 10 | 3/8 | R 3/8 | 17.2 | 2.65 | 0.852 | 0.858 | 16.662 | 19 | 11.4 | 7.7 | 5.1 | 21.3 | 26 |
| 15 | 1/2 | R 1/2 | 21.3 | 2.65 | 1.22 | 1.23 | 20.955 | 14 | 15.0 | 10.0 | 6.4 | 26.4 | 34 |
| 20 | 3/4 | R 3/5 | 26.9 | 2.65 | 1.58 | 1.59 | 26.441 | 14 | 16.3 | 11.3 | 7.7 | 31.8 | 36 |
| 25 | 1 | R 1 | 33.7 | 3.25 | 2.44 | 2.46 | 33.249 | 11 | 19.1 | 12.7 | 8.1 | 39.5 | 43 |
| 32 | 1 1/4 | R 1 1/4 | 42.4 | 3.25 | 3.14 | 3.17 | 41.910 | 11 | 21.4 | 15.0 | 10.4 | 48.3 | 48 |
| 40 | 1 1/2 | R 1 1/2 | 48.3 | 3.25 | 3.61 | 3.64 | 47.803 | 11 | 21.4 | 15.0 | 10.4 | 54.5 | 48 |
| 50 | 2 | R 2 | 60.3 | 3.65 | 5.10 | 5.17 | 59.614 | 11 | 25.7 | 18.2 | 13.6 | 66.3 | 56 |
| 65 | 2 1/2 | R 2 1/2 | 76.1 | 3.65 | 6.51 | 6.63 | 75.184 | 11 | 30.2 | 21.0 | 14.0 | 82 | 65 |
| 80 | 3 | R 3 | 88.9 | 4.05 | 8.47 | 8.64 | 87.884 | 11 | 33.3 | 241 | 17.1 | 95 | 71 |
| 100 | 4 | R4 | 114.3 | 4.5 | 12.1 | 12.4 | 113.030 | 11 | 39.3 | 28.9 | 21.9 | 122 | 83 |
| 125 | 5 | R 5 | 139.7 | 4.85 | 16.2 | 16.2 | 138.430 | 11 | 43.6 | 32.1 | 25.1 | 147 | 92 |
| 150 | 6 | R 6 | 165.1 | 4.85 | 19.2 | 19.8 | 163.830 | 11 | 43.6 | 32.1 | 25.1 | 174 | 92 |
| 1) Referred to an average length of 6m | |||||||||||||
Carbon Steel DIN 2440 Pipes are extensively utilized in industries that need robust, versatile, and cost-effective piping solutions. You’ll often find them in pipelines, structural frameworks, machinery, automotive components, and various engineering projects. They’re also essential in fabrication, manufacturing equipment, and industrial installations where mechanical strength, operational reliability, and weldability are crucial. With their outstanding durability, performance, and extended service life, Carbon Steel DIN 2440 Pipes are the go-to choice for industrial applications that prioritize safety, efficiency, and dependable performance.
