Thabiso Steel stands out as a top manufacturer and supplier located in Cape Town, South Africa, recognized for providing high-quality carbon steel products that cater to a wide range of industrial needs. One of their standout products is the **Carbon Steel EN 10083-2 Grade C25E Pipe**, designed for strength, versatility, and durability in tough applications. With a strong focus on quality, innovation, and precision, Thabiso Steel supports various sectors, including mechanical engineering, automotive, and structural industries. Thanks to their rigorous quality control and advanced production techniques, every C25E pipe is crafted to meet stringent European standards, delivering outstanding value and performance to clients throughout South Africa and beyond.
Carbon Steel EN 10083-2 Grade C25E Pipes are primarily made of carbon, manganese, silicon and small amounts of phosphorus and sulfur. These materials give the pipes excellent mechanical properties, such as high tensile strength, yield strength and elongation. The pipes are known for their superior hardness and durability, making them perfect for structural and mechanical applications. The key benefits of C25E pipes include high strength, wear resistance and excellent machinability. These qualities make them ideal for use in demanding environments, ensuring long-lasting performance and reliability.
| Specification | Details |
|---|---|
| Material | EN 10083-2 Grade C25E Carbon Steel |
| Product | Seamless Pipes and Tubes |
| Applications | General purpose applications worldwide |
| Characteristics | – Ductile and strong |
| – Long wearing properties | |
| Standard | Manufactured as per EN 10083-2 specification |
| Commercial Reference | Referred to as Carbon Steel Pipes and Tubes |
| Surface Hardness | Not as hard as high carbon steel pipes, but can be increased through carburizing |
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| 0.22-0.29 | max 0.40 | 0.40-0.70 | 0.035 | 0.035 | max 0.10 | max 0.40 | max 0.40 | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 470 | – | – | 22 | ||
| DIN | EN | BS | NFA | ASTM | ASME |
|---|---|---|---|---|---|
| – | EN 10083-2 Grade C25E | – | – | – | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
These Carbon Steel EN 10083-2 Grade C25E Pipes are made from a medium carbon steel alloy containing about **0.25% carbon**, along with carefully controlled levels of manganese, phosphorus, and sulfur. They strike a great balance between strength, ductility, and machinability. Typical mechanical properties include a **tensile strength of 430–580 MPa**, a **yield strength of around 240 MPa**, and an **elongation of about 23%**. C25E pipes are particularly well-suited for heat treatment processes like quenching and tempering, which boost their hardness and mechanical strength. Their metallurgical makeup guarantees reliable performance in structural and pressure-based applications.
| Execution | Size Range | OD Tolerance | Wall tolerance |
|---|---|---|---|
| Hot-rolled Tube | OD – 80 mmOD > 80 mmWall < 12 mmWall – 12 mm | ± 0.4 mm± 0.5 % of OD | ± 0.7 mm± (5 % x wallthickness + 0.1 mm |
| Hot-rolled peeled tube | All sizesWall < 12 mmWall – 12 mm | + 0.25/- 0 mm | ± 0.8 mm± (5 % x wall thickness+ 0.2 mm) |
| Cold Worked tubecold-rolled or cold-drawn | OD < 40 mmOD 40 – 80 mmOD > 80 Wall Thickness < 6 mm Wall Thickness6 – 8 mm Wall Thickness > 8 | + 0.30/- 0 mm*+ 0.35/- 0 mm*+ 0.40/- 0 mm* | ± 0.30 mm± 0.35 mm± 0.40 mm |
Carbon Steel EN 10083-2 Grade C25E Pipes find extensive use in general engineering, automotive components, machine parts, and structural frameworks where moderate strength and good formability are essential. These pipes are ideal for applications such as axles, shafts, hydraulic components, and mechanical fittings. Thanks to their compatibility with heat treatment and excellent machinability, they are often utilized in the production of precision parts that require tight tolerances.
